Laundry Tumble Dryer

Category:

Description

1, Since the beginning of the automatic tumble dryer, the proportion of energy consumption and efficiency of the dryer in the laundry plant has been fully considered, and the simple details have been tried to the extreme, all starting from reducing the operating cost of the user.

2, Adopt the hierarchical transmission structure , the European standard remission cone pulley with the SPA high speed belt , the transmission smooth noise is small , the maintenance is simple , the appearance is exquisite.

3, Strictly according to the national standard 1:20 volume ratio of the standard capacity of the barrel , high open hole rate cylinder , ensure that the clover full reversal space , to facilitate the combination of the grass and heat .

4, Customized multi-loop air heater to reduce heat loss and use heat efficiently . Optimization of wind tunnel design , wind volume and low noise , the air volume and evaporation area to achieve a better balance .

5, Brand motor , imported electrical drive , good load performance , high humidity , high strength is more suitable for laundry factory environment of stable operation .

Features

Model Unit HG-50

HG-100

Capacity Kg 50

100

Volume L 1000

2000

Drum Dimension mm Ф1160X980

Ф1460X1220

Power Supply V/Hz

220V/60Hz, 380V/50Hz,415V/50Hz

Motor Power kW 1.1

2.2

Fan Motor Power kW 1.5

1.5X2

Electric Heating Power kW 42

84

Steam Pressure Mpa 0.4-0.6

0.4-0.6

Gas Pressure

Mpa 0.02-0.06

0.02-0.06

Steam Consumption Kg/h 70

120

Gas Consumption Kg/h 2.4

3.2

Air Consumption m³/h 3500

8000

Height mm 2150

2550

Depth mm 1620

1950

Width mm 1320

1620

Weight Kg 700

1100
