Laundry Washing Machine

Category:

Description

1. The fully automatic washer extractor belongs to heavy duty industrial laundry washing machine, which adopts the popular suspension structure at home and abroad , combined with many year’s production technology and precipitation to optimize it , so as to ensure stable operation for many years in the laundry factory’s high-intensity operation .

2. The two-way Swedish imported brand FORSHEDA flexible sealing waterproof design, the sealing body relaxes at high speed extracting and low speed washing, and can reach the five-year replacement cycle under high frequency and high strength working conditions.

3. The upper motor structure , coupled with the washing machine special frequency converter , ventilation and heat dissipation , easy to maintain . Ensure stable operation in high temperature , high humidity and plush environment in the laundry room .

4. Using 720mm large caliber loading door , easy to operate , reduce the possibility of pulling the grass .

5. The damping spring and the hydraulic damper optimization combination , the shock absorption rate up to 98%, no need to fix the installation . In the meantime , the shaft system is fixed with special locking plate , which can avoid mechanical failure caused by vibration .

6. Adopting the domestic top brand Punp professional intelligent computer controller, the operation interface is clear at a glance, with 30 sets of automatic programs built in, which can be freely programmed.

Technical Parameters

Model

Unit

XGQ-50

XGQ-100

XGQ-130

Capacity

Kg

50

100

130

Volume

L

515

1014

1300

Cylinder dimension

mm

Ф1067X576

Ф1240X840

Ф1300X980

Wash

RPM

32

32

32

High Extract

RPM

780

720

640

G-Force

G

300

300

300

Motor Power

Kw

5.5

7.5

11

Inverter Power

Kw

7.5

11

15

Water outlet

mm

Ф140

Ф140

Ф140

Water inlet

mm

DN50

DN50X2

DN50X2

Steam Pipe

mm

DN25

DN25

DN25

Water Pressure

Mpa

0.2-0.4

0.2-0.4

0.2-0.4

Steam Pressure

Mpa

0.2-0.6

0.2-0.6

0.2-0.6

Electric Heating Power

Kw

36

72

Power Supply

V/Hz

220V/60Hz, 380V/50Hz,415V/50Hz

Noise

DB

≤75

≤75

≤75

Dimensions

Height

mm

1930

2250

2350

Depth

mm

1670

2000

2200

Width

mm

1650

1800

1850

Weight

Kg

2670

3250

3800

Water Consumption

L/load

1020

1390

1575

Steam Consumption

KG/load

50

90

130
